DRY CONCRETE PLANS

CONCRETE BATCHING PLANTS

DRY CONCRETE PLANS

The Dry plant can be characterized as a batching plant where the mixing of all components occurs in a Concrete Truck outside of the main plant. In the case of Dry Concrete plants, they are equipped with dosing stations that include all necessary components except for the Mixing unit. The ingredients are carefully weighed and discharged through a chute into the Concrete Truck, where the actual mixing process takes place. Similar to our other models, all of these Dry plants are equipped with heavy-duty gearboxes.

We take pride in offering a wide range of high-resistant materials, including thermal hardened steel and spheroidal cast iron, to ensure exceptional durability and longevity. Additionally, our Dry plants are equipped with comprehensive safety equipment to ensure compliance with Safety Standards.

clint image

DIGITAL SCALES FOR AGGREGATE

CEMENT & WATER WITH HIGH PRECISION LOAD CELLS SYSTEM
clint image

AGGREGATE EXTRACTION

CENTRAL OR SIDE
clint image

COMPACTED CONCRETE

OUTPUTS FROM 25 to 134 m3/h
clint image

CONTROL SYSTEM TYPE

Computer auto-control module + PLC SCADA system
clint image

ORIGIN

MADE IN ITALY
clint image

AGGREGATE FEED INTO MIXER

BELT CONVEYOR
PLANT  PRODUCTIVITY AGGREGATE BINS INCLINED BELT SCREW CONVEYOR DIAMETER
Mini Rapid 35 m3/h 3 Chevron 193 mm
Mobil 60 60 m3/h 4 Chevron 219 mm
Mobil 80  80 m3/h 4 Chevron 273 mm
Rapid  100/120 m3/h 5 Smooth 273 mm
Penta  120 m3/h 5 Smooth 273 mm
Esa 120 m3/h 6 Smooth 273 mm
